Pilot Whale 11 Dive LED Torches

Lumens: 3,400 lumens





We assemble this torch by hand to ensure it has the best heat sinking we can provide to sustain these outputs. This isn't one of those torches which gives 10,000 lumens for 1 minute then drops the power back (and the throw!), this sustains what it says on the tin for the duration. We put heatsinking paste around the heavy metal reflector assembly then gently screw it into the body so the damaging heat from the three high powered LEDs is transferred from the LEDs to the reflector assmbly and then to the body of the flashlight.

The Pilot Whale 11 Dive is just as comfortable on land as it is below water. The large 3,400 lumen output from the 3 LEDs provides the light needed to break through inky waters but also works just as effectively above water to create a huge pool of light in it’s beam. You have total control over this pool of light with the magnetic selector ring which allows you to choose any of the 5 output levels. We defintely sell more to people who aren't divers than we do to divers, though it can never hurt to be waterproof down to 100 metres in any application.

Light Output and Beam Pattern
Amazingly the three LEDs in their reflectors combine to give a very even beam of spot surrounded by flood. There is a lot of light in both spot and flood, all extremely even and clear – the Pilot Whale II Dive is the personal favourite of a number of staff members here due to its great even beam. As well as the quality beam, you have control over the intensity of light with the magnetic selector ring which gives you high beam, medium, medium/low, low and strobe.

Runtimes

Turbo: 70 minutes

High: 90 minutes

Medium: 220 minutes

Low: 45 hours

Construction
The 3 LEDs are mounted to a solid metal base which is screwed into the body to enable a good thermal connection to wick heat damaging away from the LEDs, important when used on land . The hand sized body houses a battery magazine housing 3 batteries, which can also be used to charge the batteries three up. The Pilot Whale II Dive LED torch is rated down to 100 metres.

Regulation
An LED torch such as the Pilot Whale 11 Dive needs to be regulated and in this case certainly is. Regulation means we regulate the amount of current reaching the LEDs to be the absolute optimum, not too much (which will overheat the LEDs and permanently damage them) but also no too little such as when the voltage reduces as the battery flattens. To solve this problem we increase the amperage as the battery flattens, so your LED flashlight has a consistent brightness.

Rechargeable Batteries
The Pilot Whale 11 Dive torch uses the same battery as almost all other Wolf Eyes torches and headlamps, the LRB168 (18650) lithium ion battery. This is housed in a 3 battery magazine for convenience when changing. These batteries are fully protected for your safety.

Australian Approved Charger
The charger supplied with your Wolf Eyes Pilot Whale 11 Dive flashlight is Australian Approved, this means you are safer when using it and that all your insurances will apply.

Waterproof
Down to 100 metres.

Support
Your Pilot Whale 11 Dive LED torch is fully supported in Australia with spare parts and also with a 1300 911 007 for any questions or queries.







A video of the strong spot surrounded by flood beam of the Pilot Whale Dive Torch
